| Model | High end tweeter |
|---|---|
| Diameter | 28 mm / 1.1″ |
| Power handling (RMS/max.) | 100 / 150 Watts |
| Impedance | 4 Ohms |
| Efficiency | 90 dB |
| Frequency Response | 1000 Hz – 30 kHz |
| Voice coil | 28 mm / 1.1″ copper |
| Cone | 2 layer coated silk |
| Mounting depth | 45 mm |
| Resonance frequency (Fs) | 630 Hz |
